1. Introduction
Cisco and Nvidia introduced a jointly developed optical module standard called USFP at the OCP Global Summit on October 13, 2026, aimed squarely at a problem that's becoming more expensive by the month: AI data centers are running out of bandwidth density faster than their racks can physically grow. Worth walking through what this standard actually changes, rather than reading it as just another vendor announcement in a crowded field of AI infrastructure news.
2. What USFP Actually Is
USFP stands for Ultra-Dense Small Form Factor Pluggable, a high-density optical pluggable module co-developed by Cisco and Nvidia specifically for Ethernet AI fabrics, the networking layer that connects GPUs, switches, and other infrastructure inside an AI data center. A pluggable optical module is the physical component that plugs into a switch port and converts electrical signals into light for transmission over fiber, and USFP's entire pitch is packing meaningfully more of that conversion capacity into the same physical footprint than today's modules can.
3. The Numbers Behind "Four Times the Density"
- Per lane: 400 Gb/s electrical signals.
- 16 lanes: 6.4 terabits of aggregate capacity, four times the bandwidth density of today's widely deployed 1.6T pluggables.
- 32 lanes: scales further to 12.8 terabits.
- Compatibility: supports both 200G and 400G SerDes-based systems and ASICs, so it doesn't force an all-or-nothing upgrade across an entire fabric at once.
- Power: Cisco estimates roughly 1.3 times better power efficiency from the 400G SerDes design.
- Serviceability: modules remain field-replaceable, so a failed module doesn't require pulling an entire switch offline.
4. The Chip Underneath It: Silicon One G302
USFP doesn't operate in isolation. It's paired with a new Cisco chip, Silicon One G302, built for top-of-rack switching in high-density AI and cloud data centers. The G302 integrates 1.6T optics directly and supports direct-to-chip liquid cooling, and Cisco has said it's planned to ship before the end of 2026. It's a different, newer chip from the existing Silicon One G300, a 102.4T chip that's already shipping today, so it's worth keeping the two distinct rather than treating "Silicon One" as a single undifferentiated product line.
5. Two New Switches, One of Them a First for Cisco
Built on the G302, Cisco introduced two fixed 64-port switches:
- Cisco 8133: a 3RU air-cooled model.
- Cisco 8132: a 2RU water-cooled model that Cisco describes as its first commercially available water-cooled switch.
That's a notable first specifically because liquid cooling at the switch level, rather than just at the server or rack level, reflects how much heat density modern AI networking gear is now expected to handle in a data center footprint that isn't growing nearly as fast as the compute packed into it.
6. The Problem This Is Actually Solving
AI infrastructure places unusually heavy demands on the connections between GPUs, switches, and security appliances, demands that don't scale the same way traditional enterprise networking traffic does. Nvidia has pointed to a specific mechanical consequence of hitting a switch's capacity ceiling: when that happens, a network needs extra switch layers and additional optical links just to keep up, and each of those additions brings its own latency, power draw, and cost. Higher bandwidth density per module is a direct answer to that specific problem: more capacity through the same physical port means fewer layers needed to move the same amount of data.
7. A Data Conflict Worth Flagging Honestly
One detail is worth naming plainly rather than smoothing over: coverage of the G302 chip cites two different bandwidth figures for it, 51.2 terabits per second in one place and 102.4 terabits per second in another, within the same reporting. That's not a small rounding difference, it's a two-times discrepancy, and as of this writing it isn't clear from the available coverage which figure is correct, or whether one number describes a different measurement basis than the other. Treating a specific chip's exact throughput as settled, when the public reporting itself hasn't settled it, would overstate how precisely this story is currently understood.
8. Why This Is Being Published as an Open Standard, Not a Lock-In
Cisco and Nvidia have said they plan to publish USFP as an open industry specification through an upcoming community-led multi-source project, rather than keeping it as a proprietary format locked to their own hardware. Nvidia's Gilad Shainer framed the goal directly: "With USFP, Nvidia and Cisco are building an ecosystem to reinvent pluggable optics." Nvidia's Brian Sparks added a clarifying point worth noting: USFP sits outside the companies' broader partnership specifically, with Cisco, Nvidia, and other ecosystem participants treating it as a shared industry direction rather than a two-company deal. Cisco's own Bill Gartner and Will Eatherton described the practical intent plainly: "USFP will provide a path supporting both 200G and 400G SerDes based systems and ASICs," language aimed at signaling compatibility across vendors rather than a closed ecosystem.
9. Building the Networking Fundamentals at Innovative Academy
Innovative Academy's Hardware & Networking program in Bangalore, which covers CCNA and CCNP-aligned networking fundamentals, builds the underlying understanding of how switching capacity, bandwidth density, and physical infrastructure actually interact, the same foundation that makes a standard like USFP legible as a real engineering response rather than just another spec sheet number.
10. FAQs
1. What problem does USFP actually solve?
It increases the amount of data a single optical module can carry, four times the density of today's common 1.6T pluggables, which reduces how many extra switch layers and optical links an AI data center needs to add as its bandwidth demands grow.
2. Is USFP a Cisco-only or Nvidia-only product?
No. It's being developed jointly and is planned for publication as an open industry specification through a multi-source project, intended to work across vendors rather than lock customers into one company's hardware.
3. Is the Silicon One G302 chip the same as the existing G300?
No, they're different chips. The G300 is a 102.4T chip already shipping today. The G302 is newer, integrates 1.6T optics directly, supports direct-to-chip liquid cooling, and is planned to ship before the end of 2026.
4. How fast is the Silicon One G302 chip exactly?
That's genuinely unclear as of this writing. Coverage of the announcement cites two different figures, 51.2 Tb/s and 102.4 Tb/s, without resolving which is accurate.
5. Does USFP require replacing an entire network's hardware at once?
No. It supports both 200G and 400G SerDes-based systems and ASICs, which allows for a staged upgrade path rather than an all-at-once replacement.
11. Final Thoughts
USFP is a genuine, specific engineering response to a real constraint: AI data centers need more bandwidth density per physical port than today's standard modules provide, and the open-specification approach suggests Cisco and Nvidia are aiming for industry-wide adoption rather than a proprietary advantage. The unresolved bandwidth figure for the G302 chip is a useful reminder that even a well-covered, significant announcement can still carry genuine ambiguity in its own early reporting, worth checking back on once Cisco publishes fuller technical documentation rather than treating either cited number as final.
